Technical Specification:

Input Voltage: 200∼240 VAC

Input Frequency: 50∼60 Hz

Max Input Current: 4 A

Main Fuses: 2×4 A

Weight: 4.5 Kg

Dimensions: 33×29×12.5 Cm

Safety Futures:

Accordance with IEC601-1(2005), IEC601-2-2(2006) & HF18

Type of Output: CF

Neutral Electrode-Earth Connection: Floating Output

HF Leakage Current: Monopolar<50 mA , Bipolar<50 mA

LF Leakage Current: Normal Condition<10 μA

Single Fault Condition<50 μA

Protection Class: I

Sink Current<500 μA
